| CPU |
AMD AM4 Socket 3rd and 2nd AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors |
| |
* Refer to www.asus.com for CPU support list |
| Chipset |
AMD X570 |
| Memory |
3rd Gen AMD Ryzen™ Processors |
| |
4 x DIMM, Max. 128GB, DDR4 MHz Un-buffered Memory |
| |
2nd Gen AMD Ryzen™ Processors |
| |
4 x DIMM, Max. 128GB, DDR4 MHz Un-buffered Memory |
| |
2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors |
| |
4 x DIMM, Max. 128GB, DDR4 MHz Un-buffered Memory |
| |
Dual Channel Memory Architecture |
| |
ECC Memory (ECC mode) support varies by CPU. |
| |
* Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists). |
| Multi-GPU Support |
3rd and 2nd Gen AMD Ryzen™ Processors |
| |
Supports NVIDIA® 3-Way SLI® Technology |
| |
Supports AMD 3-Way CrossFireX™ Technology |
| |
2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors |
| |
Supports AMD 2-Way CrossFireX™ Technology |
| Expansion Slots |
3rd Gen AMD Ryzen™ Processors |
| |
2 x PCIe 4.0 x16 (x16 or dual x8) |
| |
2nd Gen AMD Ryzen™ Processors |
| |
2 x PCIe 3.0 x16 (x16 or dual x8) |
| |
2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors |
| |
1 x PCIe 3.0 x16 (x8 mode) |
| |
AMD X570 chipset |
| |
1 x PCIe 4.0 x16 |
| |
1 x PCIe 4.0 x1 |
| Storage |
3rd Gen AMD Ryzen™ Processors : |
| |
1 x M.2_1 socket 3, with M Key, Type 2242/2260/2280 (PCIE 4.0 x4 and SATA modes) storage devices support |
| |
2nd Gen AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors : |
| |
1 x M.2_1 socket 3, with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode) |
| |
AMD X570 chipset : |
| |
1 x M.2_2 socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 4.0 x4 and SATA modes) storage devices support |
| |
8 x SATA 6Gb/s port(s), |
| |
Support Raid 0, 1, 10 |
| LAN |
Intel® I211-AT |
| |
Realtek® RTL8125-CG 2.5G LAN |
| |
ASUS LAN Guard |
| |
ROG GameFirst Technology |
| Audio |
ROG SupremeFX 8-Channel High Definition Audio CODEC |
| |
– Impedance sense for front and rear headphone outputs |
| |
– Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking |
| |
– High quality 120 dB SNR stereo playback output and 113 dB SNR recording input |
| |
– SupremeFX Shielding Technology |
| |
– ESS® ES9023P |
| |
– Supports up to 32-Bit/192kHz playback |
| |
Audio Feature : |
| |
– Sonic Studio III + Sonic Studio Virtual Mixer |
| |
– DTS® Sound Unbound |
| |
– Optical S/PDIF out port(s) at back panel |
| |
– Sonic Radar III |
| |
* Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for 8-Channel audio. |
| USB Ports |
3rd Gen AMD RyzenTM Processors : |
| |
4 x USB 3.2 Gen 2 port(s) |
| |
2nd Gen AMD RyzenTM/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors : |
| |
4 x USB 3.2 Gen 1 port(s) |
| |
AMD X570 chipset : |
| |
1 x USB 3.2 Gen 2 front panel connector port(s) |
| |
AMD X570 chipset : |
| |
4 x USB 3.2 Gen 2 port(s) |
| |
AMD X570 chipset : |
| |
6 x USB 3.2 Gen 1 port(s) |
| |
AMD X570 chipset : |
| |
4 x USB 2.0 port(s) |
| ROG Exclusive Features |
Extreme Engine Digi+ : |
| |
– IR3555 PoweIRstage® |
| |
– MicroFine Alloy Chokes |
| |
– 10K Black Metallic Capacitors |
| |
ROG Extreme OC kit : |
| |
– OptiMem III |
| |
– Safe Boot button |
| |
– Slow Mode |
| |
– LN2 Mode |
| |
Extreme Tweaker |
| |
ROG Patented Pre-mounted I/O Shield |
| |
ROG Exclusive Software |
| |
– Sonic Studio III + Sonic Studio Virtual Mixer |
| |
– RAMCache III |
| |
– RAMDisk |
| |
– CPU-Z |
| |
– GameFirst V |
| |
– Sonic Radar III |
| Special Features |
ASUS Dual Intelligent Processors 5-Way Optimization by Dual Intelligent Processors 5 : |
| |
– 5-Way Optimization tuning key perfectly consolidates TPU, EPU, DIGI+ VRM, Fan Expert 4, and Turbo App |
| |
AURA : |
| |
– Aura Lighting Effects Synchronization with compatible ASUS ROG devices |
| |
ASUS Exclusive Features : |
| |
– USB BIOS Flashback® |
| |
– AI Suite 3 |
| |
– Ai Charger |
| |
– ASUS CrashFree BIOS 3 |
| |
– Armoury Crate |
| |
– ASUS NODE: hardware control interface |
| |
– ASUS EZ Flash 3 |
| |
– ASUS C.P.R.(CPU Parameter Recall) |
| |
– Clear CMOS Button |
| |
– Reset Button |
| |
– Start Button |
| |
– ReTry button |
| |
ASUS Q-Design : |
| |
– ASUS Q-Code |
| |
– ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED) |
| |
– ASUS Q-Slot |
| |
– ASUS Q-DIMM |
| |
– ASUS Q-Connector |
| Back I/O Ports |
1 x Optical S/PDIF out |
| |
1 x Clear CMOS button(s) |
| |
1 x Anti-surge 2.5G LAN (RJ45) port |
| |
1 x USB BIOS Flashback® Button(s) |
| |
5 x Gold-plated audio jacks |
| |
4 x USB 3.2 Gen 1 (up to 5Gbps) ports |
| |
8 x USB 3.2 Gen 2 (up to 10Gbps) ports () |
| |
Anti-surge LAN (RJ45) port |
| Internal I/O Ports |
2 x Aura RGB Strip Headers |
| |
2 x Addressable Gen 2 header(s) |
| |
2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s) |
| |
1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support |
| |
1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support |
| |
1 x TPM connector(s) |
| |
8 x SATA 6Gb/s connector(s) |
| |
1 x CPU Fan connector(s) |
| |
1 x CPU OPT Fan connector(s) |
| |
3 x Chassis Fan connector(s) |
| |
1 x AIO_PUMP connector |
| |
1 x H_AMP fan connector |
| |
1 x W_PUMP+ connector |
| |
1 x 4-pin EATX 12 V Power connector |
| |
1 x 24-pin EATX Power connector(s) |
| |
1 x 8-pin EATX 12V Power connectors |
| |
1 x Front panel audio connector(s) (AAFP) |
| |
1 x Slow Mode switch(es) |
| |
1 x Reset button(s) |
| |
1 x Node Connector(s) |
| |
1 x LN2 Mode jumper(s) |
| |
1 x Safe Boot button |
| |
1 x ReTry button |
| |
1 x System panel connector |
| |
1 x T_Sensor Connector |
| |
1 x W_IN header |
| |
1 x W_OUT header |
| |
1 x W_FLOW header |
| |
1 x Start button |
| |
1 x Speaker connector |
| |
1 x USB 3.2 Gen 2 (up to 10Gbps) connector |
| |
1 x USB 3.2 Gen 1 (up to 5Gbps) connector support additional 2 USB ports |
| Accessories |
User’s manual |
| |
4 x SATA 6Gb/s cable(s) |
| |
1 x M.2 Screw Package |
| |
1 x Supporting DVD |
| |
1 x ROG big sticker |
| |
1 x Q-Connector |
| |
1 x Extension Cable for RGB strips (80 cm) |
| |
1 x Extension cable for Addressable LED |
| |
1 x ROG coaster(s) |
| |
1 x ROG Thank you card |
| BIOS |
256 Mb Flash ROM, UEFI AMI BIOS, PnP, WfM2.0, SM BIOS 3.2, ACPI 6.2 |
| Manageability |
WOL, PXE |
| Operating System |
Windows® 10 64-bit |
| Form Factor |
ATX Form Factor |
| |
12 inch x 9.6 inch ( 20.5 cm x 24.4 cm ) |
