| Model |
GT-AX11000 |
| Network Standard |
IEEE 802.11a |
| |
IEEE 802.11b |
| |
IEEE 802.11g |
| |
IEEE 802.11n |
| |
IEEE 802.11ac |
| |
IEEE 802.11ax |
| |
IPv4 |
| |
IPv6 |
| Product Segment |
AX11000 ultimate AX performance |
| Coverage |
Very large homes |
| Data Rate |
802.11a : 6,9,12,18,24,36,48,54 Mbps |
| |
802.11b : 1, 2, 5.5, 11 Mbps |
| |
802.11g : 6,9,12,18,24,36,48,54 Mbps |
| |
802.11n : up to 600 Mbps |
| |
802.11n (1024 QAM) : up to 1000 Mbps |
| |
802.11ac (1024 QAM) : up to 4333 Mbps |
| |
802.11ax (2.4GHz) : up to 1148 Mbps |
| |
802.11ax (5GHz) : up to 4804 Mbps |
| Antenna |
External antenna x 8 |
| Transmit/Receive |
2.4 GHz 4 x 4 |
| |
5 GHz-1 4 x 4 |
| |
5 GHz-2 4 x 4 |
| Processor |
256 MB Flash |
| |
1 GB RAM |
| Memory |
256 MB Flash |
| |
1024 MB RAM |
| Wi-Fi Technology |
OFDMA (Orthogonal Frequency Division Multiple Access) |
| |
Beamforming: standard-based and universal |
| |
1024-QAM high data rate |
| |
20/40/80/160 MHz bandwidth |
| Operating Frequency |
2.4G Hz |
| |
5 GHz-1 |
| |
5 GHz-2 |
| Encryption |
WPA2-PSK |
| |
WPA-PSK |
| |
WPA-Enterprise |
| |
WPA2-Enterprise |
| |
WPS support |
| Firewall & Access Control |
Access control：Parental control, Network service filter, URL filter, Port filter |
| Management |
UPnP, IGMP v1/v2/v3, DNS Proxy, DHCP, NTP Client, DDNS, Port Trigger, Port Forwarding, DMZ, System Event Log |
| VPN Support |
IPSec Pass-Through |
| |
PPTP Pass-Through |
| |
L2TP Pass-Through |
| |
PPTP server |
| |
OpenVPN server |
| |
PPTP client |
| |
L2TP client |
| |
OpenVPN client |
| WAN Connection Type |
Internet connection type : Automatic IP, Static IP, PPPoE(MPPE supported), PPTP, L2TP |
| Utilities |
Router setup wizard; Firmware restoration; Device discovery; printer setup utility |
| Ports |
RJ45 for Gigabits BaseT for WAN x 1, RJ45 for Gigabits BaseT for LAN x 4, Support Ethernet and 802.3 with max. bit rate 2.5Gbps Mbps and auto cross-over function(MDI-X) |
| |
USB 3.1 Gen 1 x 2 |
| Features |
Link Aggregation |
| |
802.3ad |
| |
MU-MIMO |
| |
Traffic Analyzer |
| |
Adaptive QoS |
| |
WTFast Gamers Private Network |
| |
AiProtection Pro |
| |
Parental Control |
| |
Guest Network : 2.4 GHz x 3, 5 GHz-1 x 3, 5 GHz-2 x 3 |
| |
VPN server : IPSec Pass-Through, PPTP Pass-Through, L2TP Pass-Through, PPTP Server, OpenVPN Server |
| |
VPN client : PPTP client, L2TP client, OpenVPN client |
| |
Mac OS Backup |
| |
Enhanced media server (AiPlayer app compatible) |
| |
Image : Jpeg |
| |
Audio : mp3, wma, wav, pcm, mp4, lpcm, ogg |
| |
Video : asf, avi, divx, mpeg, mpg, ts, vob, wmv, mkv, mov |
| |
AiCloud personal cloud service |
| |
3G/4G data sharing |
| |
Printer Server |
| |
Multifunctional printer support (Windows only) |
| |
LPR protocol support |
| |
Download Master |
| |
Support bt, nzb, http, ed2k |
| |
Support encryption, DHT, PEX and magnet link |
| |
Upload and download bandwidth control |
| |
Download scheduling |
| |
AiDisk file server |
| |
Samba and FTP server with account management |
| |
Dual WAN |
| |
IPTV support |
| |
Roaming Assist |
| Button |
WPS Button, Reset Button, Power Button, Wireless on/off Button, LED on/off Button |
| LED Indicator |
Power x 1 |
| |
Wi-Fi x 2 |
| |
WAN x 1 |
| |
LAN x 1 |
| |
USB x 2 |
| |
WPS x 1 |
| |
2.5G Port x 1 |
| Power Supply |
AC Input : 110V~240V(50~60Hz) |
| |
DC Output : 19 V with max. 3.42 A current |
| OS Support |
Windows® 10 |
| |
Windows® 8 |
| |
Windows® 7 |
| |
Mac OS X 10.6 |
| |
Mac OS X 10.7 |
| |
Mac OS X 10.8 |
| Dimensions |
240 x 240 x 60 mm (WxDxH) g |
| Color |
Black |
| Operation mode |
Wireless router mode |
| |
Access point mode |
| |
Media bridge mode |
| Warranty |
3 Years |
